C type lifter table
Name：C type lifter table
Detailed
Lifter table size： 1550*1342mm*90mm (oversize is not fixed, maybe changeable)
Working height： 90～900mm
Hydraulic station: 0.75kW
Two legs opening is : 600+-10mm
Machine weight： 350KGS
Cylinder QTY： 2 pcs*OD50mm
Oil cylinder stroke: 175mm
Max loading : 1000kgs
Option:
1.Table size can be customized made;
2.Automatic lifting sensor device for lifting up or lift down.
